Siddhgiri Tubes is one of the renowned names in the market. We are manufacturer, exporter, supplier of Alloy 20 Sheets and Plates.
Alloy 20 Sheets & Plates, Alloy 20 Sheets & Plates Manufacturers, Alloy 20 Sheets & Plates Suppliers, Alloy 20 Sheets & Plates Stockists, Alloy 20 Sheets & Plates Exporters
The alloy 20 steel Sheets & Platess are made of austenitic stainless steel. These steel sheets plates are composed of nickel, iron, and chromium.This makes these plates much tougher and hard.
Alloy 20 Sheets & Plates in India, Alloy 20 Sheets & Plates Manufacturers in India, Alloy 20 Sheets & Plates Suppliers in India, Alloy 20 Sheets & Plates Stockists in India, Alloy 20 Sheets & Plates Exporters in India
They are also resistive to different types of corrosions such as to the hostile environment, pitting and crevice corrosion. These plates are also good at welding and fabrication.
Alloy 20 Sheets & Plates in Mumbai, Alloy 20 Sheets & Plates Manufacturers in Mumbai, Alloy 20 Sheets & Plates Suppliers in Mumbai, Alloy 20 Sheets & Plates Stockists in Mumbai, Alloy 20 Sheets & Plates Exporters in Mumbai
Our high-grade Alloy N08020 Sheets and Plates are having some most beneficial characteristics like better efficiency, leak-proof, corrosion resistance, etc. some finishing we provide the long-life service to our clients. We focus on the satisfaction of our clients.
Specification Chart of Alloy 20 Sheets & Plates
| Standard | ASTM B463 / ASME SB463 |
|---|---|
| Dimensions | JIS, AISI, ASTM, GB, DIN, EN, etc |
| Thickness | Ranging from 0.3mm to 20mm |
| Length | 2000 mm / 2440 mm / 2500 mm / 3000 mm / 6000 mm |
| Hardness | As per ASME A & NACE MR 175 |
| Width | 1000mm / 1219mm /1250mm / 1500mm / 2000mm |
| Finish | Hot rolled plate (HR), Cold rolled sheet (CR) |
| Value added services for Plates | Waterjet cutting, Plasma cutting, Laser cutting, Bending and mechanical processing, edge preparation, welding, sawing and shearing |
Chemical Composition Of Alloy 20 Sheets & Plates
| Grade | C | Mn | Si | S | Cu | Ni | Cr | Fe | Mo | P |
|---|---|---|---|---|---|---|---|---|---|---|
| Alloy 20 | 0.07 max | 2.00 max | 1.00 max | 0.035 max | 3.00 – 4.00 | 32.00 – 38.00 | 19.00 – 21.00 | 29.85 min* | 2.00 – 3.00 | 0.045 max |
Mechanical Properties Of Alloy 20 Sheets & Plates
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|---|
| Alloy 20 | 8.1 g/cm3 | 1443 °C (2430 °F) | Psi -80,000, MPa -551 | Psi - 35,000, MPa - 241 | 30 % |
